About the yacht
16 m
80 m
The main characteristics
Building and superstructure material:
Steel
Full length (L.O.A):
75 m + 5 m platform total: 80 m
Maximum width (b):
16 m
Displacement:
65 tons
Maximum design speed:
14 knots
Cruising speed:
9 knots
The main engines:
2 to 2000 h.p.
Deck:
6
Cabins:
111
Passengers:
250
Want to know more about the capabilities of the yacht?
Request detailed information from our specialists.
Get a consultation
The decks of the yacht
The device of the yacht
1. Yacht housing and structural details
- The case of the yacht is designed both a half -breeding, to ensure both comfort when swimming and sufficient efficiency. Made.
- The material for the manufacture of the housing will be a ship plate 3701. Racks, structural reinforcements and waterproof bulkheads will also be made of steel.
2. Details of the superstructure of the yacht
- The superstructure will be made of steel. The superstructure form will be formed using corners, lamellas and profiles.
- Elements of strengthening the structure will be made of composite material formed from polyurethane foam and fibers.
3. External coloring and decoration
- The case and superstructure will be finished with epoxy primer, epoxy putty and the upper layer of epoxy -based paint. Preferences on the color of the paint of the upper layer will be determined by the owner of the vessel, and alternative options will be offered by the manufacturer.
- An epoxy primer is applied to the underwater parts of the case, an anti -forming primer and the upper layer of anti -shaping paint.
4. General characteristic
- The yacht is designed as 8 main sections, 7 decks.
- Units (places of tanks)
- 1 deck (steering, machine department, electric shock, galley, storage of hot and cold air, cabins and household rooms of the crew, nasal steering wheel),
- The main deck (sea landing platforms, a yacht garage zone, a pool, customer cabins and an anchor lift section)
- 1st deck (cabins for customers)
- 2nd deck (fodder cockpit, lobby, cabins for customers and master cakes)
- 3rd deck (bar, restaurant part, VIP cakes, jacuzzi and zone for tanning)
- 4th deck (bar, entertainment zone, master cakes, steering wheel, zone for the adoption of sunbathing and rest)
- 5th deck (bar, recreation area and acceptance of sunbathing)
5. Decking coatings
- All decks will be covered with ticus or similar massive wood.
6. The main engines and the movement system
- The main engines are two in 2200 hp. The engines are selected in such a way as to ensure the maximum design speed of 14 knots and the cruising speed of 9 knots.
- Maneuverability will be increased due to the nasal stooping device.
- The drive will be carried out through a rowing shaft and a five -lobed screw.
7. Tanks
- In the machine department, four fuel tank will be placed with a total capacity of 30,000 liters. To reduce the risk of fire, the tanks will be made of steel and equipped with the necessary valve systems in case of emergency situations.
- Fresh water tank will be installed with a volume of 30,000 liters. The location of the tank will be determined by the designer/engineer of the vessel, taking into account the calculations of sustainability.
- A tank for wastewater with a volume of 10,000 liters will be installed. The location of the tank will also be determined on the basis of stability calculations.
- A tank for gray water with a volume of 5,000 liters will be installed, its location will be determined by an engineer/designer, taking into account the calculations of sustainability.
8. Power supply system
- The main voltage on the yacht is 380 V.
- The main power source will be two diesel generators.
- The yacht will be equipped with a sufficient number of batteries and inverters. This system will be a secondary power source that provides electronics and household electrical equipment. A separate group of batteries will be created for starting engines.
- For batteries, a charging system will be installed.
- The yacht will be equipped with a system of connection to coastal electricity for use while parking.
9. Electronics and navigation system
- Electronics equipment includes:
- Radar
- GPS
- EchoLot
- Log (speed meter)
- Electronic Card Plotter
- Radio VHF
- Autopilot
- Standard electronics equipment will be Raymarine or similar, with warranty service. The warranty periods depend on the manufacturer and may vary depending on the type and model of equipment.
10. Other equipment
- The yacht will be equipped with the desaliner of fresh water. The capacity and model of equipment will be determined by the engineer/manufacturer of the vessel.
- A hydraulic plot of 2000 kg will be installed on the yacht.
- The yacht will be equipped with a bathing staircase and hydraulic doors.
- For the anchor system, two anchor winches and a sufficient number of mooring winches will be installed. The capacity and model of equipment will be determined by the engineer/manufacturer of the vessel. The chain and anchor will be set by the manufacturer with the vessel.
- To ensure safety, external openings will be equipped with leers. Lero will be made of chrome steel 316L and manufactured in accordance with the standards in height.
11. Pumps and systems
- The yacht will be equipped with a pumping system. In each waterproof compartment, automatic holds of the Rule brand or similar will be installed. The pumps will be directly connected to the batteries so that the system functions even in the absence of a crew on board. A fire pump will be used as a reserve system of holding.
- The yacht will be equipped with a fire system. A fire pump with sufficient power will be installed by an engineer of the vessel and connected to a sprinkler system for residential areas.
- To supply drinking and technical water, the yacht will be equipped with a fresh water system. The system will provide hot and cold water in bathrooms and kitchen. Fresh water will be supplied through the hydrophor, and hot - through the boiler. The capacity of the hydrophore and boiler will be determined by the engineer of the vessel.
- A wastewater system will be installed on the yacht. For pumping wastewater, a pump will be installed from the tank, as well as connecting elements for connecting to the coastal system.
- The yacht will be equipped with an air conditioning system, which will provide climate control in the cabin and cabins. The system will be centralized for uniform distribution of chilled air.
- When passing the yacht, all systems will be accompanied by design schemes, technical drawings and operating instructions.
12. Interior rooms
- The main cabins will be equipped with double beds, as well as individual bathrooms with a shower and a toilet. Each cabin has a desktop, a dressing room and a mini-chill.
- VIP cakes for guests will be equipped with double beds and balconies (terraces), as well as bathrooms with shower and toilet.
- Guest cabins will be equipped with double beds and their own bathrooms with a shower and a toilet.
- The ceilings of all cabins will be sheathed with artificial skin. Furniture will be mainly from high -quality laminated plywood.
- In all cabins there will be cabinets for clothes and TVs for the convenience of passengers.
13. Zones for tanning, rest and entertainment
- All zones for tanning, rest and entertainment will be equipped with a musical, light and other necessary system in the calculation of the total capacity of the yacht.
